OpenTelemetry、Kafka、ClickHouseによる大容量分散トレーシング

# otel-collector-config.yaml
receivers:
  otlp:
    protocols:
      grpc:
        endpoint: 0.0.0.0:4317 # Standard OTLP gRPC port
      http:
        endpoint: 0.0.0.0:4318 # Standard OTLP HTTP port

# otel-collector-config.yaml
processors:
  batch:
    send_batch_size: 1024 # Target batch size
    timeout: 5s         # Max time to wait for a batch
  memory_limiter:
    check_interval: 1s
    limit_mib: 2048     # Max 2GB memory usage
    spike_limit_mib: 512 # Max 512MB spike
  tail_sampling:
    decision_wait: 10s # How long to wait for a trace to complete before making a sampling decision
    num_traces: 100000 # Max number of traces to hold in memory for sampling
    expected_new_traces_per_sec: 10000 # Expected new traces per second
    policies:
      [
        {
          name: "always-sample-errors",
          type: status_code,
          status_code: {
            status_codes: [ERROR, UNSET], # Keep traces with ERROR or UNSET status
            drop_nested_spans: false
          }
        },
        {
          name: "drop-ok-traces",
          type: probabilistic,
          probabilistic: {
            sampling_percentage: 5 # Keep 5% of all other traces (e.g., 200 OK)
          }
        }
      ]

# otel-collector-config.yaml
exporters:
  kafka:
    brokers: ["kafka-broker-1:9092", "kafka-broker-2:9092"]
    topic: "opentelemetry-traces"
    encoding: "otlp_json" # Export in OTLP JSON format for easier consumption
    protocol_version: "2.0.0"
    # Essential for production: buffer spans if Kafka is unavailable
    sending_queue:
      enabled: true
      queue_size: 5000 # Number of batches to buffer (e.g., 5000 * 1024 spans)
    # Optional: Configure retries for transient Kafka issues
    retry_on_failure:
      enabled: true
      initial_interval: 5s
      max_interval: 30s
      max_elapsed_time: 5m

# otel-collector-config.yaml
service:
  pipelines:
    traces:
      receivers: [otlp]
      processors: [memory_limiter, tail_sampling, batch]
      exporters: [kafka]

CREATE TABLE IF NOT EXISTS traces.spans
(
    `trace_id` String CODEC(ZSTD(1)),
    `span_id` String CODEC(ZSTD(1)),
    `parent_span_id` String CODEC(ZSTD(1)),
    `trace_state` String CODEC(ZSTD(1)),
    `service_name` LowCardinality(String) CODEC(ZSTD(1)),
    `operation_name` LowCardinality(String) CODEC(ZSTD(1)),
    `kind` LowCardinality(String) CODEC(ZSTD(1)),
    `start_time_us` UInt64 CODEC(Delta, ZSTD(1)),
    `end_time_us` UInt64 CODEC(Delta, ZSTD(1)),
    `duration_us` UInt64 CODEC(Delta, ZSTD(1)),
    `status_code` UInt8 CODEC(ZSTD(1)),
    `status_message` String CODEC(ZSTD(1)),
    `attributes` Map(LowCardinality(String), String) CODEC(ZSTD(1)),
    `resource_attributes` Map(LowCardinality(String), String) CODEC(ZSTD(1)),
    `events.time_unix_nano` Array(UInt64) CODEC(Delta, ZSTD(1)),
    `events.name` Array(LowCardinality(String)) CODEC(ZSTD(1)),
    `events.attributes` Array(Map(LowCardinality(String), String)) CODEC(ZSTD(1)),
    `links.trace_id` Array(String) CODEC(ZSTD(1)),
    `links.span_id` Array(String) CODEC(ZSTD(1)),
    `links.trace_state` Array(String) CODEC(ZSTD(1)),
    `links.attributes` Array(Map(LowCardinality(String), String)) CODEC(ZSTD(1)),
    `ingestion_time_ms` DateTime64(3, 'UTC') DEFAULT now() CODEC(Delta, ZSTD(1))
)
ENGINE = MergeTree
PARTITION BY toYYYYMMDD(toDateTime(start_time_us / 1000000))
ORDER BY (service_name, start_time_us, trace_id, span_id)
PRIMARY KEY (service_name, start_time_us)
TTL toDateTime(start_time_us / 1000000) + INTERVAL 30 DAY
SETTINGS index_granularity = 8192, merge_with_ttl_timeout = 3600;

-- Secondary index for faster trace_id lookups
ALTER TABLE traces.spans ADD INDEX trace_id_idx trace_id TYPE bloom_filter GRANULARITY 1;

CREATE TABLE IF NOT EXISTS traces.spans_kafka_raw
(
    `trace_id` String,
    `span_id` String,
    `parent_span_id` String,
    `trace_state` String,
    `service_name` String,
    `operation_name` String,
    `kind` String,
    `start_time_us` UInt64,
    `end_time_us` UInt64,
    `duration_us` UInt64,
    `status_code` UInt8,
    `status_message` String,
    `attributes` String, -- Raw JSON string for attributes
    `resource_attributes` String, -- Raw JSON string for resource attributes
    `events.time_unix_nano` Array(UInt64),
    `events.name` Array(String),
    `events.attributes` Array(String), -- Raw JSON string for event attributes
    `links.trace_id` Array(String),
    `links.span_id` Array(String),
    `links.trace_state` Array(String),
    `links.attributes` Array(String) -- Raw JSON string for link attributes
)
ENGINE = Kafka
SETTINGS
    kafka_broker_list = 'kafka-broker-1:9092,kafka-broker-2:9092',
    kafka_topic_list = 'opentelemetry-traces',
    kafka_group_name = 'clickhouse_otel_consumer_group',
    kafka_format = 'JSONEachRow', -- OTLP JSON is essentially JSONEachRow
    kafka_num_consumers = 4, -- Number of parallel consumers
    kafka_max_block_size = 1048576, -- Max bytes per block
    kafka_skip_broken_messages = 10; -- Skip up to 10 broken messages per block

CREATE MATERIALIZED VIEW IF NOT EXISTS traces.spans_mv TO traces.spans AS
SELECT
    JSONExtractString(message, 'resource.attributes.service.name') AS service_name, -- Extract service name from resource attributes
    JSONExtractString(message, 'span_id') AS span_id,
    JSONExtractString(message, 'trace_id') AS trace_id,
    JSONExtractString(message, 'parent_span_id') AS parent_span_id,
    JSONExtractString(message, 'trace_state') AS trace_state,
    JSONExtractString(message, 'name') AS operation_name,
    JSONExtractString(message, 'kind') AS kind,
    JSONExtractUInt(message, 'start_time_unix_nano') / 1000 AS start_time_us,
    JSONExtractUInt(message, 'end_time_unix_nano') / 1000 AS end_time_us,
    (JSONExtractUInt(message, 'end_time_unix_nano') - JSONExtractUInt(message, 'start_time_unix_nano')) / 1000 AS duration_us,
    JSONExtractUInt(message, 'status.code') AS status_code,
    JSONExtractString(message, 'status.message') AS status_message,
    JSONExtract(message, 'attributes', 'Map(LowCardinality(String), String)') AS attributes,
    JSONExtract(message, 'resource.attributes', 'Map(LowCardinality(String), String)') AS resource_attributes,
    arrayMap(x -> JSONExtractUInt(x, 'time_unix_nano'), JSONExtractArrayRaw(message, 'events')) AS `events.time_unix_nano`,
    arrayMap(x -> JSONExtractString(x, 'name'), JSONExtractArrayRaw(message, 'events')) AS `events.name`,
    arrayMap(x -> JSONExtract(x, 'attributes', 'Map(LowCardinality(String), String)'), JSONExtractArrayRaw(message, 'events')) AS `events.attributes`,
    arrayMap(x -> JSONExtractString(x, 'trace_id'), JSONExtractArrayRaw(message, 'links')) AS `links.trace_id`,
    arrayMap(x -> JSONExtractString(x, 'span_id'), JSONExtractArrayRaw(message, 'links')) AS `links.span_id`,
    arrayMap(x -> JSONExtractString(x, 'trace_state'), JSONExtractArrayRaw(message, 'links')) AS `links.trace_state`,
    arrayMap(x -> JSONExtract(x, 'attributes', 'Map(LowCardinality(String), String)'), JSONExtractArrayRaw(message, 'links')) AS `links.attributes`
FROM traces.spans_kafka_raw;

SELECT
    trace_id,
    span_id,
    parent_span_id,
    service_name,
    operation_name,
    kind,
    start_time_us,
    duration_us,
    status_code,
    status_message,
    attributes,
    resource_attributes
FROM traces.spans
WHERE trace_id = 'a1b2c3d4e5f6a7b8c9d0e1f2a3b4c5d6'
ORDER BY start_time_us ASC;

SELECT
    trace_id,
    service_name,
    operation_name,
    start_time_us,
    duration_us,
    status_code,
    status_message
FROM traces.spans
WHERE service_name = 'my-critical-service'
  AND status_code != 0 -- OTLP status_code 0 is OK
  AND toDateTime(start_time_us / 1000000) BETWEEN '2023-10-26 00:00:00' AND '2023-10-26 23:59:59'
ORDER BY start_time_us DESC
LIMIT 100;

SELECT
    operation_name,
    avg(duration_us) AS avg_duration_us,
    count() AS total_spans
FROM traces.spans
WHERE service_name = 'my-api-gateway'
  AND toDateTime(start_time_us / 1000000) BETWEEN now() - INTERVAL 1 HOUR AND now()
GROUP BY operation_name
ORDER BY avg_duration_us DESC
LIMIT 10;

SELECT
    trace_id,
    service_name,
    operation_name,
    attributes['http.method'] AS http_method,
    attributes['http.status_code'] AS http_status_code
FROM traces.spans
WHERE service_name = 'my-web-app'
  AND attributes['http.method'] = 'POST'
  AND attributes['http.status_code'] = '500'
  AND toDateTime(start_time_us / 1000000) BETWEEN now() - INTERVAL 1 DAY AND now()
LIMIT 50;
