How to Build a Custom Playwright Reporter for Next.js Dashboards

Locionic
Locionic
https://x.com/Locionic
playwrighttestingautomationnextjs
How to Build a Custom Playwright Reporter for Next.js Dashboards
Table of Contents(9 sections)

Building a custom reporter for Playwright is the most effective way to stream live test automation results into your own Next.js dashboard. Instead of relying on static HTML reports or paying for third-party services, you can write a dedicated reporter that captures exact test metrics and posts them directly to your backend, giving your team a private, self-hosted analytics platform with zero vendor lock-in.

In this guide, you will learn exactly how to implement a custom JSON reporter in Playwright, build a receiving API route in Next.js, add flakiness tracking, support CI sharding across multiple runners, and persist results to PostgreSQL via Prisma.

Audio Briefing
0:00 / 0:00

Why Standard HTML Reports Fall Short

Standard Playwright HTML reports serve a single purpose: show pass/fail for a single test run. They provide no historical tracking, no flakiness detection across runs, no team-wide dashboard, and no integration with your alerting systems.

When you have a team running thousands of tests daily across multiple CI pipelines, you need:

  • Historical trend data: Is test stability improving after a refactor?
  • Flakiness leaderboard: Which tests pass only on retry?
  • Per-branch visibility: Did this PR introduce new failures?
  • Real-time streaming: Can developers see results as they run, not after?

A custom Playwright reporter solves all of this by implementing Playwright's built-in Reporter interface and posting structured data to your own API.

Advertisement

Implementing the Playwright Reporter Interface

Playwright exposes a Reporter interface with lifecycle hooks that fire at precise moments during a test run. The key hooks are:

  • onBegin(config, suite): called once when the test run starts
  • onTestBegin(test, result): called before each individual test
  • onTestEnd(test, result): called after each test completes (pass, fail, or skip)
  • onEnd(result): called once when the entire run finishes

Create dashboard-reporter.ts in your Playwright project root:

import type {
  Reporter,
  TestCase,
  TestResult,
  FullResult,
  Suite,
  FullConfig,
} from '@playwright/test/reporter';

interface TestPayload {
  testId: string;
  title: string;
  fullTitle: string;
  filePath: string;
  status: 'passed' | 'failed' | 'flaky' | 'skipped' | 'timedOut';
  retryCount: number;
  durationMs: number;
  workerIndex: number;
  errorMessage: string | null;
  errorStack: string | null;
  attachmentUrls: string[];
}

interface RunPayload {
  runId: string;
  branch: string;
  commitSha: string;
  status: FullResult['status'];
  startedAt: string;
  finishedAt: string;
  totalTests: number;
  passedTests: number;
  failedTests: number;
  flakyTests: number;
  skippedTests: number;
  tests: TestPayload[];
}

class NextjsDashboardReporter implements Reporter {
  private results: TestPayload[] = [];
  private startedAt: string = '';
  private runId: string;
  private dashboardUrl: string;

  constructor(options: { dashboardUrl?: string } = {}) {
    this.runId = process.env.CI_RUN_ID ?? crypto.randomUUID();
    this.dashboardUrl =
      options.dashboardUrl ??
      process.env.DASHBOARD_URL ??
      'http://localhost:3000';
  }

  onBegin(_config: FullConfig, _suite: Suite) {
    this.startedAt = new Date().toISOString();
    console.log(`[Reporter] Run ${this.runId} started at ${this.startedAt}`);
  }

  onTestEnd(test: TestCase, result: TestResult) {
    // A test that passed but only after retries is flaky
    const isFlaky = result.status === 'passed' && result.retry > 0;

    this.results.push({
      testId: test.id,
      title: test.title,
      fullTitle: test.titlePath().join(' > '),
      filePath: test.location.file,
      status: isFlaky ? 'flaky' : result.status,
      retryCount: result.retry,
      durationMs: result.duration,
      workerIndex: result.workerIndex ?? -1,
      errorMessage: result.errors[0]?.message?.slice(0, 2000) ?? null,
      errorStack: result.errors[0]?.stack?.slice(0, 4000) ?? null,
      // Attachments are uploaded to S3/R2 separately; we store only URLs
      attachmentUrls: result.attachments
        .filter((a) => a.path)
        .map((a) => `${this.dashboardUrl}/artifacts/${this.runId}/${a.name}`),
    });
  }

  async onEnd(result: FullResult) {
    const payload: RunPayload = {
      runId: this.runId,
      branch: process.env.GITHUB_REF_NAME ?? 'local',
      commitSha: process.env.GITHUB_SHA ?? 'unknown',
      status: result.status,
      startedAt: this.startedAt,
      finishedAt: new Date().toISOString(),
      totalTests: this.results.length,
      passedTests: this.results.filter((t) => t.status === 'passed').length,
      failedTests: this.results.filter((t) => t.status === 'failed').length,
      flakyTests: this.results.filter((t) => t.status === 'flaky').length,
      skippedTests: this.results.filter((t) => t.status === 'skipped').length,
      tests: this.results,
    };

    try {
      const response = await fetch(`${this.dashboardUrl}/api/reports`, {
        method: 'POST',
        headers: {
          'Content-Type': 'application/json',
          'x-reporter-secret': process.env.REPORTER_SECRET ?? '',
        },
        body: JSON.stringify(payload),
      });

      if (!response.ok) {
        console.error(`[Reporter] Upload failed: ${response.status} ${await response.text()}`);
      } else {
        console.log(`[Reporter] Run ${this.runId} uploaded successfully.`);
      }
    } catch (err) {
      // Never let reporter errors crash the CI process
      console.error('[Reporter] Network error during upload:', err);
    }
  }
}

export default NextjsDashboardReporter;

Register the reporter in playwright.config.ts:

import { defineConfig } from '@playwright/test';

export default defineConfig({
  reporter: [
    ['list'],                                    // Console output during run
    ['./dashboard-reporter.ts', {               // Custom dashboard reporter
      dashboardUrl: process.env.DASHBOARD_URL,
    }],
  ],
});

Building the Next.js API Receiver

The API route validates the incoming payload, writes to PostgreSQL, and returns immediately. Using the App Router at app/api/reports/route.ts:

import { NextResponse } from 'next/server';
import { prisma } from '@/lib/prisma';

const REPORTER_SECRET = process.env.REPORTER_SECRET;

export async function POST(request: Request) {
  // Validate the shared secret
  if (REPORTER_SECRET) {
    const secret = request.headers.get('x-reporter-secret');
    if (secret !== REPORTER_SECRET) {
      return NextResponse.json({ error: 'Unauthorized' }, { status: 401 });
    }
  }

  const data = await request.json();

  // Upsert the run record (idempotent for CI sharding where multiple workers post)
  const run = await prisma.testRun.upsert({
    where: { runId: data.runId },
    create: {
      runId: data.runId,
      branch: data.branch,
      commitSha: data.commitSha,
      status: data.status,
      startedAt: new Date(data.startedAt),
      finishedAt: new Date(data.finishedAt),
      totalTests: data.totalTests,
      passedTests: data.passedTests,
      failedTests: data.failedTests,
      flakyTests: data.flakyTests,
      skippedTests: data.skippedTests,
    },
    update: {
      // Merge shard results: aggregate counts
      totalTests: { increment: data.totalTests },
      passedTests: { increment: data.passedTests },
      failedTests: { increment: data.failedTests },
      flakyTests: { increment: data.flakyTests },
      skippedTests: { increment: data.skippedTests },
      status: data.status === 'failed' ? 'failed' : undefined,
      finishedAt: new Date(data.finishedAt),
    },
  });

  // Batch-insert all individual test results
  await prisma.testResult.createMany({
    data: data.tests.map((t: any) => ({
      runId: run.id,
      testId: t.testId,
      title: t.title,
      fullTitle: t.fullTitle,
      filePath: t.filePath,
      status: t.status,
      retryCount: t.retryCount,
      durationMs: t.durationMs,
      workerIndex: t.workerIndex,
      errorMessage: t.errorMessage,
    })),
    skipDuplicates: true,
  });

  return NextResponse.json({ success: true, runId: run.runId });
}

Prisma Schema for Test Persistence

model TestRun {
  id          Int          @id @default(autoincrement())
  runId       String       @unique
  branch      String
  commitSha   String
  status      String
  startedAt   DateTime
  finishedAt  DateTime
  totalTests  Int          @default(0)
  passedTests Int          @default(0)
  failedTests Int          @default(0)
  flakyTests  Int          @default(0)
  skippedTests Int         @default(0)
  results     TestResult[]
  createdAt   DateTime     @default(now())

  @@index([branch])
  @@index([commitSha])
}

model TestResult {
  id           Int     @id @default(autoincrement())
  run          TestRun @relation(fields: [runId], references: [id])
  runId        Int
  testId       String
  title        String
  fullTitle    String
  filePath     String
  status       String
  retryCount   Int     @default(0)
  durationMs   Int
  workerIndex  Int
  errorMessage String?

  @@index([testId])
  @@index([status])
  @@index([filePath])
}
Advertisement

Flakiness Dashboard Query

With results persisted, you can compute per-test flakiness rates across branches with a single query:

// Top 10 flaky tests in the last 30 days
const flakyLeaderboard = await prisma.testResult.groupBy({
  by: ['testId', 'fullTitle', 'filePath'],
  where: {
    run: { startedAt: { gte: new Date(Date.now() - 30 * 86400_000) } },
  },
  _count: { testId: true },
  _sum: { retryCount: true },
  having: { retryCount: { _sum: { gt: 0 } } },
  orderBy: { _sum: { retryCount: 'desc' } },
  take: 10,
});

CI Sharding Support

Playwright CI sharding splits your test suite across multiple runners for speed. Each shard runs independently and posts its results to the same endpoint. Because the API route uses upsert keyed on runId (set via CI_RUN_ID), all shards merge into a single unified run record:

# .github/workflows/e2e.yml
strategy:
  matrix:
    shardIndex: [1, 2, 3, 4]
    shardTotal: [4]
env:
  CI_RUN_ID: ${{ github.run_id }}-${{ github.run_attempt }}
  DASHBOARD_URL: ${{ secrets.DASHBOARD_URL }}
  REPORTER_SECRET: ${{ secrets.REPORTER_SECRET }}

Each of the 4 shards posts its CI_RUN_ID, and the aggregate counts accumulate correctly in the database via the upsert increment logic.

Test Your Knowledge

Frequently Asked Questions

Running a custom dashboard costs very little. If you deploy your receiver to Vercel and store telemetry in Supabase or serverless Neon PostgreSQL, operational costs are virtually zero for small to medium engineering teams.
Yes. Instead of sending large binary files inside the JSON payload, upload artifacts directly to Cloudflare R2 or Amazon S3 using presigned URLs during test execution, and include only the signed artifact URLs in the reporter payload. This keeps the JSON payload small and avoids timeout issues.
No. Playwright executes test lifecycle hooks asynchronously. In-memory data aggregation happens in the background, and the network payload is dispatched in the onEnd hook after all tests complete. The only overhead is the final HTTP POST, which is typically under 500ms.
Yes. Pass a shared CI_RUN_ID environment variable to all runner shards. Each worker shard posts its batch to the Next.js API with the same run ID, and the upsert logic in the database aggregates them into a unified test run view with correct aggregate counts.
In the API route's onEnd handler, after persisting the results, check if data.failedTests > 0 and data.branch === 'main'. If so, make an additional fetch call to a Slack webhook or PagerDuty Events API v2. This gives you real-time alerting without a separate CI step.
