PostgreSQLの変更データキャプチャ(CDC): Debezium、Kafka Connect、トランザクションアウトボックス

# postgresql.conf
wal_level = logical
max_replication_slots = 10 # Adjust based on number of Debezium connectors
max_wal_senders = 10       # Adjust based on number of Debezium connectors

-- Connect as a superuser or a user with REPLICATION privileges
SELECT * FROM pg_create_logical_replication_slot('debezium_slot', 'pgoutput');

SELECT slot_name, plugin, active, wal_status, restart_lsn FROM pg_replication_slots;

# Example: Distributed Kafka Connect worker configuration (connect-distributed.properties)
bootstrap.servers=kafka-broker-1:9092,kafka-broker-2:9092
group.id=connect-cluster
config.storage.topic=connect-configs
offset.storage.topic=connect-offsets
status.storage.topic=connect-statuses
key.converter=io.confluent.connect.avro.AvroConverter
key.converter.schema.registry.url=http://schema-registry:8081
value.converter=io.confluent.connect.avro.AvroConverter
value.converter.schema.registry.url=http://schema-registry:8081
internal.key.converter=org.apache.kafka.connect.json.JsonConverter
internal.value.converter=org.apache.kafka.connect.json.JsonConverter
internal.key.converter.schemas.enable=false
internal.value.converter.schemas.enable=false
plugin.path=/usr/share/java,/usr/share/confluent-hub-components

{
  "name": "postgres-connector",
  "config": {
    "connector.class": "io.debezium.connector.postgresql.PostgresConnector",
    "tasks.max": "1",
    "database.hostname": "postgres-db",
    "database.port": "5432",
    "database.user": "debezium_user",
    "database.password": "debezium_password",
    "database.dbname": "your_database",
    "database.server.name": "your_logical_server_name",
    "schema.include.list": "public",
    "table.include.list": "public.users,public.orders",
    "slot.name": "debezium_slot",
    "publication.name": "debezium_publication",
    "publication.autocreate.mode": "all_tables",
    "plugin.name": "pgoutput",
    "topic.prefix": "dbserver",
    "heartbeat.interval.ms": "5000",
    "snapshot.mode": "initial",
    "decimal.handling.mode": "double",
    "time.precision.mode": "connect",
    "hstore.handling.mode": "json",
    "converters": "dateConverter",
    "dateConverter.type": "org.apache.kafka.connect.data.Timestamp",
    "dateConverter.format": "yyyy-MM-dd HH:mm:ss.SSS",
    "key.converter": "io.confluent.connect.avro.AvroConverter",
    "key.converter.schema.registry.url": "http://schema-registry:8081",
    "value.converter": "io.confluent.connect.avro.AvroConverter",
    "value.converter.schema.registry.url": "http://schema-registry:8081"
  }
}

curl -X POST -H "Content-Type: application/json" --data @debezium-connector.json http://kafka-connect:8083/connectors

CREATE TABLE outbox (
    id UUID PRIMARY KEY,
    aggregatetype VARCHAR(255) NOT NULL,
    aggregateid UUID NOT NULL,
    type VARCHAR(255) NOT NULL,
    payload JSONB NOT NULL,
    createdat TIMESTAMP WITH TIME ZONE DEFAULT CURRENT_TIMESTAMP
);

import { Pool } from 'pg';
import { v4 as uuidv4 } from 'uuid';

interface User {
  id: string;
  name: string;
  email: string;
}

interface OutboxEvent {
  id: string;
  aggregateType: string;
  aggregateId: string;
  type: string;
  payload: any;
}

class UserService {
  private pool: Pool;

  constructor(pool: Pool) {
    this.pool = pool;
  }

  public async createUser(name: string, email: string): Promise<User> {
    const client = await this.pool.connect();
    try {
      await client.query('BEGIN');

      const userId = uuidv4();
      const user: User = { id: userId, name, email };

      // 1. Persist business entity
      await client.query(
        'INSERT INTO users (id, name, email) VALUES ($1, $2, $3)',
        [user.id, user.name, user.email]
      );

      // 2. Create outbox event
      const event: OutboxEvent = {
        id: uuidv4(),
        aggregateType: 'User',
        aggregateId: user.id,
        type: 'UserCreated',
        payload: { userId: user.id, name: user.name, email: user.email, timestamp: new Date().toISOString() },
      };

      // 3. Persist outbox event in the same transaction
      await client.query(
        'INSERT INTO outbox (id, aggregatetype, aggregateid, type, payload) VALUES ($1, $2, $3, $4, $5)',
        [event.id, event.aggregateType, event.aggregateId, event.type, JSON.stringify(event.payload)]
      );

      await client.query('COMMIT');
      return user;
    } catch (error) {
      await client.query('ROLLBACK');
      console.error('Failed to create user and publish event:', error);
      throw error;
    } finally {
      client.release();
    }
  }
}

// Example usage (assuming 'pool' is a configured pg.Pool instance)
// const userService = new UserService(pool);
// userService.createUser('John Doe', 'john.doe@example.com')
//   .then(user => console.log('User created:', user))
//   .catch(err => console.error('Error:', err));

import { Kafka, Consumer } from 'kafkajs';
import { Pool } from 'pg';

interface UserCreatedEvent {
  userId: string;
  name: string;
  email: string;
  timestamp: string;
}

class UserEventHandler {
  private consumer: Consumer;
  private pool: Pool;

  constructor(kafka: Kafka, pool: Pool) {
    this.consumer = kafka.consumer({ groupId: 'user-service-consumer-group' });
    this.pool = pool;
  }

  public async start(): Promise<void> {
    await this.consumer.connect();
    await this.consumer.subscribe({ topic: 'dbserver.public.outbox', fromBeginning: false });

    await this.consumer.run({
      eachMessage: async ({ topic, partition, message }) => {
        if (!message.value) return;

        const event = JSON.parse(message.value.toString());
        const outboxEventId = event.payload.id; // The ID from the outbox table, our idempotency key
        const operation = event.op; // 'c' for create, 'u' for update, 'd' for delete

        if (operation !== 'c') {
          // We only care about new outbox events, not updates/deletes to the outbox table itself
          return;
        }

        const payload = event.after.payload; // Debezium 'after' field contains the new row
        const eventType = event.after.type;

        if (eventType === 'UserCreated') {
          const userCreatedEvent: UserCreatedEvent = payload;
          await this.processUserCreatedEvent(outboxEventId, userCreatedEvent);
        }
        // Handle other event types
      },
    });
  }

  private async processUserCreatedEvent(outboxEventId: string, event: UserCreatedEvent): Promise<void> {
    const client = await this.pool.connect();
    try {
      await client.query('BEGIN');

      // Check for idempotency: has this event ID been processed before?
      const checkResult = await client.query(
        'SELECT 1 FROM processed_events WHERE event_id = $1',
        [outboxEventId]
      );

      if (checkResult.rows.length > 0) {
        console.log(`Event ${outboxEventId} already processed. Skipping.`);
        await client.query('ROLLBACK'); // Rollback the transaction as nothing new was done
        return;
      }

      // Process the event (e.g., create a user in a read model, send a welcome email)
      console.log(`Processing UserCreated event for user ${event.userId}:`, event);
      // Example: Insert into a read-model table
      await client.query(
        'INSERT INTO read_model_users (id, name, email) VALUES ($1, $2, $3) ON CONFLICT (id) DO NOTHING',
        [event.userId, event.name, event.email]
      );

      // Record the event ID as processed
      await client.query(
        'INSERT INTO processed_events (event_id, processed_at) VALUES ($1, NOW())',
        [outboxEventId]
      );

      await client.query('COMMIT');
      console.log(`Successfully processed event ${outboxEventId}`);
    } catch (error) {
      await client.query('ROLLBACK');
      console.error(`Error processing event ${outboxEventId}:`, error);
      throw error;
    } finally {
      client.release();
    }
  }
}

// Ensure 'processed_events' table exists for idempotency tracking
// CREATE TABLE processed_events (
//     event_id UUID PRIMARY KEY,
//     processed_at TIMESTAMP WITH TIME ZONE DEFAULT CURRENT_TIMESTAMP
// );

// Example usage
// const kafka = new Kafka({ brokers: ['kafka-broker-1:9092'] });
// const userEventHandler = new UserEventHandler(kafka, pool);
// userEventHandler.start().catch(console.error);
