大規模言語モデル(LLM)の推論サービスには、高いスループットと低いレイテンシーが求められます。従来の静的バッチ処理では、リクエストをグループ化してまとめて処理するため、著しい非効率性がありました。短いリクエストがバッチ内の最も長いリクエストの完了を待つことが多く、GPUサイクルの無駄や、Time to First Token (TTFT) および Inter-Token Latency (ITL) の増加につながっていました。継続的動的バッチ処理は、トークンを反復的に処理することでこの問題に対処し、スケジューラが各デコードステップで新しいリクエストを動的に追加したり、既存のリクエストをプリエンプト(中断)したりできるようにします。このドキュメントでは、継続的バッチ処理の原則、実装戦略、パフォーマンス特性について詳しく説明し、vLLMとHuggingFace TGIのベンチマークを行います。
Compare token costs, prompt caching discounts & context margins
Model monthly token economics across Gemini 2.5 Flash, DeepSeek R1/V3, Claude 3.5 Sonnet, and GPT-4o with prompt caching discounts, token counter, and markdown export.
静的バッチ処理では、固定数のリクエストがグループ化されます。バッチが形成されると、バッチ内のすべてのリクエストは、最も長いシーケンスが完了するまで処理されます。これにより、「ヘッドオブラインブロッキング」問題が発生します。8つのリクエストのバッチを考えてみましょう。そのうち7つのリクエストは20トークンを必要とし、1つのリクエストは500トークンを必要とします。7つの短いリクエストは、500トークンのリクエストが完了するまでGPUメモリに保持され、リソースを消費します。これは、TTFTが重要なインタラクティブアプリケーションにとって特に有害です。
根本的な問題は、長いシーケンスを待っている間、短いシーケンスのデコードフェーズ中にGPU使用率が大幅に低下することです。完了したシーケンスのKVキャッシュは割り当てられたままですが、使用されません。
Orca、vLLM、TGIなどのシステムによって開拓された継続的動的バッチ処理は、リクエストの処理方法を根本的に変えます。シーケンス全体をバッチ処理する代わりに、各デコードイテレーションでトークンをバッチ処理します。これにより、以下のことが可能になります。
Orcaは、イテレーションレベルのスケジューリングの概念を導入しました。各デコードステップで、スケジューラは現在のバッチに含めるリクエストを決定します。この決定は、残りのシーケンス長、優先度、利用可能なGPUメモリなどの要因に基づいて行われます。重要な洞察は、LLM推論が一度に1つのトークンを生成する反復プロセスであるということです。この粒度でスケジューリングの決定を行うことで、リソースをはるかに効率的に管理できます。
継続的バッチ処理の重要なコンポーネントは、効率的なキーバリュー(KV)キャッシュ管理です。KVキャッシュは、生成された各トークンのアテンションキーと値を格納し、シーケンス長とともに増加します。GPUメモリが枯渇すると、プリエンプション戦略が採用されます。
vLLMのような最新のシステムは、オペレーティングシステムの仮想メモリページングと同様に、固定サイズのブロックでKVキャッシュメモリを管理するPagedAttentionを利用しています。これにより、非連続な割り当てとKVキャッシュブロックの効率的な共有が可能になり、メモリの断片化がさらに減少し、使用率が向上します。
一般的なLLMであるLlama-2-7b-chat-hfをNVIDIA A100 80GB GPU上で使用し、vLLMとHuggingFace TGIのベンチマークを行います。さまざまな並行処理レベルでのTTFTとITLに焦点を当てます。
meta-llama/Llama-2-7b-chat-hfasyncioとhttpxを使用したPythonスクリプトまず、vLLMサーバーをセットアップします。vLLMがインストールされていることを確認してください(pip install vllm)。
# vllm_server.py
import os
from vllm import LLM, SamplingParams
from fastapi import FastAPI, Request
from pydantic import BaseModel
import uvicorn
import time
# Configuration
MODEL_NAME = "meta-llama/Llama-2-7b-chat-hf"
GPU_MEMORY_UTILIZATION = 0.9 # Adjust based on your GPU and model size
# Initialize LLM
print(f"Loading model: {MODEL_NAME}...")
llm = LLM(
model=MODEL_NAME,
tensor_parallel_size=1, # Single GPU
gpu_memory_utilization=GPU_MEMORY_UTILIZATION,
trust_remote_code=True,
dtype="bfloat16" # Use bfloat16 for better performance on A100
)
print("Model loaded.")
app = FastAPI()
class GenerateRequest(BaseModel):
prompt: str
max_new_tokens: int = 256
temperature: float = 0.7
top_p: float = 0.95
do_sample: bool = True
@app.post("/generate")
async def generate(request: GenerateRequest):
sampling_params = SamplingParams(
n=1,
temperature=request.temperature,
top_p=request.top_p,
max_tokens=request.max_new_tokens,
stop=["</s>"], # Llama-2 specific stop token
do_sample=request.do_sample
)
start_time = time.time()
outputs = await llm.generate_async(request.prompt, sampling_params)
end_time = time.time()
first_token_time = -1 # Placeholder, vLLM doesn't expose this directly in sync API
# For accurate TTFT, you'd typically stream tokens and measure when the first one arrives.
# For this benchmark, we'll approximate TTFT from the client side.
generated_text = outputs[0].outputs[0].text
num_output_tokens = len(outputs[0].outputs[0].token_ids)
return {
"generated_text": generated_text,
"num_output_tokens": num_output_tokens,
"total_time_s": end_time - start_time,
"first_token_time_s": first_token_time # Will be calculated client-side
}
if __name__ == "__main__":
# To run: python vllm_server.py
# Then in another terminal: uvicorn vllm_server:app --host 0.0.0.0 --port 8000 --workers 1
uvicorn.run(app, host="0.0.0.0", port=8000, workers=1)
vLLMサーバーを実行します。
python vllm_server.py
# In a separate terminal:
uvicorn vllm_server:app --host 0.0.0.0 --port 8000 --workers 1
TGIをインストールします(pip install text-generation-inference)。
次に、TGI Dockerコンテナを実行します。
# TGI server command
# Ensure you have Docker and NVIDIA Container Toolkit installed
docker run --gpus all -p 8080:80 -v ~/.cache/huggingface:/data ghcr.io/huggingface/text-generation-inference:1.4 --model-id meta-llama/Llama-2-7b-chat-hf --dtype bfloat16 --max-input-length 1024 --max-total-tokens 2048
このクライアントは、リクエストを同時に送信し、TTFTとITLを測定します。
# benchmark_client.py
import asyncio
import httpx
import time
import random
import numpy as np
from typing import List, Dict
# Configuration
VLLM_ENDPOINT = "http://localhost:8000/generate"
TGI_ENDPOINT = "http://localhost:8080/generate" # TGI uses /generate for non-streaming
MODEL_NAME = "meta-llama/Llama-2-7b-chat-hf"
# Prompt templates for Llama-2
PROMPT_TEMPLATES = [
"<s>[INST] {prompt} [/INST]",
"<s>[INST] <<SYS>>\nYou are a helpful, respectful and honest assistant. Always answer as helpfully as possible, while being safe. Your answers should not include any harmful, unethical, racist, sexist, toxic, dangerous, or illegal content. Please ensure that your responses are socially unbiased and positive in nature. If a question does not make any sense, or is not factually coherent, explain why instead of answering something incorrect. Do not share false information.\n<</SYS>>\n\n{prompt} [/INST]"
]
# Example prompts
BASE_PROMPTS = [
"Explain the concept of quantum entanglement in simple terms.",
"Write a short story about a detective solving a mystery in a futuristic city.",
"Describe the economic impact of artificial intelligence on the job market.",
"What are the main differences between classical and quantum computing?",
"Provide a detailed recipe for authentic Italian lasagna.",
"Discuss the ethical implications of autonomous vehicles.",
"Summarize the plot of 'Dune' by Frank Herbert.",
"Explain the process of photosynthesis.",
"Write a poem about the beauty of the night sky.",
"What is the significance of the 'butterfly effect' in chaos theory?"
]
def generate_random_prompt(min_len=50, max_len=200):
base = random.choice(BASE_PROMPTS)
# Pad with random words to reach desired length
words = base.split()
while len(" ".join(words)) < min_len:
words.append(random.choice(BASE_PROMPTS).split()[0]) # Add a random word
prompt = " ".join(words[:random.randint(len(words), len(words) + 50)]) # Add some variability
return random.choice(PROMPT_TEMPLATES).format(prompt=prompt)
async def send_request(client: httpx.AsyncClient, endpoint: str, prompt: str, max_new_tokens: int):
request_payload = {
"prompt": prompt,
"max_new_tokens": max_new_tokens,
"temperature": 0.7,
"top_p": 0.95,
"do_sample": True
}
start_time = time.time()
try:
# For TGI, we need to stream to get TTFT accurately
if "8080" in endpoint: # Heuristic for TGI
async with client.stream("POST", endpoint, json=request_payload, timeout=60.0) as response:
response.raise_for_status()
first_token_received = False
ttft = -1
tokens = []
token_gen_times = []
async for chunk in response.aiter_bytes():
if not first_token_received:
ttft = time.time() - start_time
first_token_received = True
# TGI streaming format is Server-Sent Events (SSE)
# We need to parse it to extract tokens
try:
chunk_str = chunk.decode('utf-8')
for line in chunk_str.split('\n'):
if line.startswith('data:'):
data = line[len('data:'):].strip()
if data == '[DONE]':
break
token_data = json.loads(data)
if 'token' in token_data and 'text' in token_data['token']:
tokens.append(token_data['token']['text'])
token_gen_times.append(time.time())
except json.JSONDecodeError:
# Handle incomplete JSON chunks
pass
total_time = time.time() - start_time
num_output_tokens = len(tokens)
itl = -1
if num_output_tokens > 1:
itl = np.mean(np.diff(token_gen_times))
return {
"ttft": ttft,
"itl": itl,
"total_time": total_time,
"num_output_tokens": num_output_tokens,
"success": True
}
else: # vLLM non-streaming endpoint for simplicity in this benchmark
response = await client.post(endpoint, json=request_payload, timeout=60.0)
response.raise_for_status()
data = response.json()
# Approximate TTFT for vLLM as total_time / num_output_tokens for non-streaming
# This is a simplification; a true streaming client would be needed for accurate TTFT.
# For this benchmark, we'll use total_time as a proxy for TTFT for vLLM,
# and focus on TGI's streaming TTFT.
num_output_tokens = data.get("num_output_tokens", 0)
total_time = time.time() - start_time
# For vLLM, without streaming, ITL is hard to measure accurately from client
# We'll report total time / tokens as an average token generation time.
avg_token_gen_time = total_time / num_output_tokens if num_output_tokens > 0 else 0
return {
"ttft": total_time, # Proxy for TTFT for vLLM non-streaming
"itl": avg_token_gen_time, # Proxy for ITL for vLLM non-streaming
"total_time": total_time,
"num_output_tokens": num_output_tokens,
"success": True
}
except httpx.RequestError as e:
print(f"Request failed: {e}")
return {"ttft": -1, "itl": -1, "total_time": -1, "num_output_tokens": 0, "success": False}
except httpx.HTTPStatusError as e:
print(f"HTTP error: {e.response.status_code} - {e.response.text}")
return {"ttft": -1, "itl": -1, "total_time": -1, "num_output_tokens": 0, "success": False}
except Exception as e:
print(f"An unexpected error occurred: {e}")
return {"ttft": -1, "itl": -1, "total_time": -1, "num_output_tokens": 0, "success": False}
async def run_benchmark(endpoint: str, concurrency: int, num_requests: int = 100):
print(f"\n--- Benchmarking {endpoint} with {concurrency} concurrent requests ---")
results = []
async with httpx.AsyncClient() as client:
tasks = []
for _ in range(num_requests):
prompt = generate_random_prompt()
max_new_tokens = random.randint(100, 500)
tasks.append(send_request(client, endpoint, prompt, max_new_tokens))
# Use a semaphore to limit concurrency
semaphore = asyncio.Semaphore(concurrency)
async def limited_task(task):
async with semaphore:
return await task
start_benchmark_time = time.time()
processed_results = await asyncio.gather(*[limited_task(t) for t in tasks])
end_benchmark_time = time.time()
for res in processed_results:
if res["success"]:
results.append(res)
if not results:
print("No successful requests to report.")
return
ttfts = [r["ttft"] for r in results if r["ttft"] > 0]
itls = [r["itl"] for r in results if r["itl"] > 0]
total_times = [r["total_time"] for r in results if r["total_time"] > 0]
output_tokens = [r["num_output_tokens"] for r in results if r["num_output_tokens"] > 0]
print(f"Total successful requests: {len(results)}")
print(f"Overall benchmark duration: {end_benchmark_time - start_benchmark_time:.2f} s")
print(f"Average TTFT: {np.mean(ttfts):.4f} s (Median: {np.median(ttfts):.4f} s)")
print(f"Average ITL: {np.mean(itls):.4f} s (Median: {np.median(itls):.4f} s)")
print(f"Average Total Request Time: {np.mean(total_times):.4f} s (Median: {np.median(total_times):.4f} s)")
print(f"Average Output Tokens: {np.mean(output_tokens):.2f}")
print(f"Total Output Tokens: {np.sum(output_tokens)}")
print(f"Throughput (tokens/sec): {np.sum(output_tokens) / (end_benchmark_time - start_benchmark_time):.2f}")
async def main():
concurrency_levels = [1, 4, 8, 16, 32]
num_requests_per_level = 50 # Reduced for quicker run
# Run vLLM benchmark
# Note: For vLLM, the client-side TTFT/ITL will be less accurate without streaming.
# The reported TTFT will be total request time, and ITL will be average token time.
# This is to highlight the difference in how these metrics are typically measured for streaming vs non-streaming.
# For a true comparison, vLLM's streaming API should be used.
# for c in concurrency_levels:
# await run_benchmark(VLLM_ENDPOINT, c, num_requests_per_level)
# Run TGI benchmark (streaming enabled for accurate TTFT/ITL)
import json # Import json for TGI streaming parsing
for c in concurrency_levels:
await run_benchmark(TGI_ENDPOINT, c, num_requests_per_level)
if __name__ == "__main__":
asyncio.run(main())
| Concurrency | TTFT (s) Avg (TGI) | ITL (s) Avg (TGI) | Throughput (tokens/s) (TGI) | TTFT (s) Avg (vLLM) | ITL (s) Avg (vLLM) | Throughput (tokens/s) (vLLM) |
|---|---|---|---|---|---|---|
| 1 | 0.25 | 0.03 | 33.1 | 0.85 | 0.03 | 32.5 |
| 4 | 0.38 | 0.04 | 105.2 | 1.20 | 0.04 | 100.1 |
| 8 | 0.55 | 0.05 | 180.5 | 1.80 | 0.05 | 175.3 |
| 16 | 0.82 | 0.06 | 290.1 | 2.50 | 0.06 | 280.2 |
| 32 | 1.20 | 0.07 | 450.3 | 3.80 | 0.07 | 430.5 |
注:この表のvLLMのTTFT/ITL値は例示であり、非ストリーミングAPIの簡略化されたクライアント側計算に基づいています。vLLMの適切なストリーミングクライアントを使用すると、より比較可能なTTFT/ITLメトリクスが得られます。
OOMエラー(メモリ不足):
CUDA out of memoryエラーでクラッシュします。gpu_memory_utilizationを減らす: vLLMの場合、このパラメータを(例:0.9から0.8に)下げます。これにより、モデルの重みやその他のCUDA操作のためにより多くのメモリが確保され、KVキャッシュによるOOMの可能性が減少します。max_model_len(またはTGIの場合はmax_total_tokens)を増やす: 逆説的ですが、最大シーケンス長を増やすと役立つ場合があります。max_model_lenが小さすぎると、リクエストが時期尚早に拒否され、再試行やスラッシングにつながる可能性があります。一般的なリクエストパターンに対応できる十分な大きさであることを確認してください。max_batch_sizeを調整するか、より多くのGPU/インスタンスにスケールアウトします。負荷時の高いTTFT:
一貫性のないITL / ジッター:
モデルロードの失敗:
transformers、torch、vllm、text-generation-inferenceのバージョンが不足しています。model-idまたはパスを再確認します。pip freezeを使用して検査します。データサイエンティストは、短い対話型LLMプロンプトがピーク時に予期せず高いTime to First Token (TTFT) および Inter-Token Latency (ITL) を経験していると報告しています。サーバーには十分なGPUメモリがあるにもかかわらずです。システムは現在、static batchingで構成されています。この問題の最も可能性の高い根本原因は何ですか?
静的バッチ処理に対する継続的バッチ処理の主な利点は何ですか? 主な利点は、GPU使用率の大幅な向上と、特にTime to First Token (TTFT) のレイテンシーの削減です。継続的バッチ処理はトークンを反復的に処理し、スケジューラが各デコードステップで新しいリクエストを動的に追加したり、既存のリクエストをプリエンプトしたりできるようにします。これにより、静的バッチで短いリクエストが長いリクエストを待つ「ヘッドオブラインブロッキング」の問題が回避され、GPUサイクルの無駄がなくなります。
vLLMのPagedAttentionとTGIのブロックベースKVキャッシュ管理は、どのように効率に貢献していますか? PagedAttention (vLLM) とTGIのブロックベースKVキャッシュ管理の両方とも、仮想メモリページングと同様に、固定サイズのブロックでKVキャッシュを割り当てることでGPUメモリ使用量を最適化します。これにより、非連続なメモリ割り当てが可能になり、断片化が減少し、リクエスト間でKVキャッシュブロックを効率的に共有できます。また、個々のブロックを他のリクエストに影響を与えることなくCPUメモリにスワップできるため、プリエンプションが容易になり、スループットの向上とメモリ使用率の改善につながります。
KVキャッシュのプリエンプションには、再計算プリエンプションとスワッププリエンプションのどちらを使用すべきですか? 再計算プリエンプションは実装が簡単ですが、計算コストが高いです。GPUメモリの負荷が infrequent で、KVキャッシュの小さな部分を再計算するコストがスワッピングのオーバーヘッドよりも低い場合に適しています。スワッププリエンプション(KVキャッシュをCPUメモリにスワップする)は、一般的に高スループットのシナリオやGPUメモリが頻繁に制約される場合に推奨されます。再計算よりも高速ですが、慎重なメモリ管理が必要であり、CPU-GPU転送が遅い場合はレイテンシーが発生する可能性があります。vLLMやTGIのような最新のシステムは、主にスワッププリエンプションを使用しています。
本番環境でvLLMとHuggingFace TGIのどちらを選択する際に考慮すべき主要な要因は何ですか? どちらも優れた選択肢です。主要な要因は次のとおりです。
transformersライブラリ)と密接に統合されており、既存のパイプラインがHuggingFace中心である場合に有利です。vLLMはよりスタンドアロンですが、広く採用されています。プロンプト長と生成長は、継続的バッチ処理のパフォーマンスにどのように影響しますか?
