Kubernetes HPA with Custom Metrics: Practical Autoscaling with Prometheus

Kubernetes Horizontal Pod Autoscaler (HPA) is a fundamental component for managing application elasticity. While scaling based on CPU and memory utilization is a common starting point, it often fails to capture the true load and performance characteristics of modern applications. Effective autoscaling requires metrics directly correlated with application demand, such as HTTP request rates, message queue depth, or active user sessions.

This article provides a pragmatic, code-rich guide to configuring Kubernetes HPA v2 with custom and external metrics using the Prometheus Adapter. We will demonstrate how to scale deployments based on real-world application metrics, moving beyond generic resource utilization.

Understanding Kubernetes HPA and Metrics

The Horizontal Pod Autoscaler automatically scales the number of pods in a deployment, stateful set, or replica set based on observed metrics.

HPA v1 vs. HPA v2

• HPA v1: Limited to scaling based on CPU utilization only.
• HPA v2: Introduced support for multiple metrics, including resource metrics (CPU, memory), custom metrics, and external metrics. This significantly enhances HPA's flexibility and applicability to diverse workloads.

Metric Types for Autoscaling

1. Resource Metrics:

   • Description: CPU and memory utilization reported by pods. These are collected by the Kubernetes Metrics Server.
   • Use Case: General-purpose scaling for applications where CPU/memory directly correlates with load.
   • Limitation: Often an indirect indicator of actual application demand. A CPU-bound application might scale well, but an I/O-bound or latency-sensitive application might not.

2. Custom Metrics:

   • Description: Application-specific metrics exposed by pods, typically via a /metrics endpoint in Prometheus format. These metrics are directly associated with a Kubernetes object (e.g., a Deployment, Service, or Pod).
   • Use Case: Scaling based on application-level indicators like HTTP request rate, active connections, or internal queue sizes.
   • Example: http_requests_total per pod.

3. External Metrics:

   • Description: Metrics originating from external systems not directly tied to a specific Kubernetes object. These metrics are often global or represent a shared resource.
   • Use Case: Scaling based on external queue depth (e.g., SQS, Kafka topic lag), database connection pool utilization, or external API call rates.
   • Example: Total messages in an SQS queue, independent of any single pod.

How HPA Works

The HPA controller continuously queries the Kubernetes Metrics API (for resource metrics) or the Custom/External Metrics APIs (for custom/external metrics). Based on the configured target values and current metric observations, it calculates the desired number of replicas and updates the target workload (Deployment, ReplicaSet, etc.).

The formula for desired replicas is generally:

desiredReplicas = ceil[currentReplicas * (currentMetricValue / targetMetricValue)]

Architecture Overview: Prometheus Adapter for Custom Metrics

To enable HPA to consume custom and external metrics from Prometheus, the Kubernetes ecosystem provides the Prometheus Adapter.

The flow is as follows:

1. Application: Your application exposes metrics in Prometheus format (e.g., http_requests_total, queue_messages_total) via an HTTP endpoint (/metrics).
2. Prometheus: A Prometheus instance scrapes these metrics from your application pods using ServiceMonitors or PodMonitors.
3. Prometheus Adapter:
   • Deploys as an API server within your Kubernetes cluster.
   • Implements the custom.metrics.k8s.io and external.metrics.k8s.io APIs.
   • Translates requests from the HPA controller into Prometheus queries based on predefined rules.
   • Executes these queries against the Prometheus instance.
   • Returns the query results to the HPA controller in the expected API format.
4. HPA Controller: Queries the Custom/External Metrics APIs exposed by the Prometheus Adapter and adjusts the replica count of your application deployment.

Setting Up the Environment

This section assumes you have a functional Kubernetes cluster and kubectl configured.

1. Install Prometheus Stack

We will use the kube-prometheus-stack Helm chart, which includes Prometheus, Grafana, and the Prometheus Operator.

# Add the Prometheus community Helm repository
helm repo add prometheus-community https://prometheus-community.github.io/helm-charts
helm repo update

# Create a namespace for monitoring components
kubectl create namespace monitoring

# Install kube-prometheus-stack
helm install prometheus prometheus-community/kube-prometheus-stack \
  --namespace monitoring \
  --set prometheus.prometheusSpec.serviceMonitorSelectorNilUsesHelmValues=false \
  --set prometheus.prometheusSpec.podMonitorSelectorNilUsesHelmValues=false

The serviceMonitorSelectorNilUsesHelmValues and podMonitorSelectorNilUsesHelmValues flags are crucial. They ensure that Prometheus automatically discovers ServiceMonitors and PodMonitors deployed in the same namespace as Prometheus, or those explicitly labeled to be discovered.

2. Install Prometheus Adapter

The Prometheus Adapter is installed via its dedicated Helm chart. The critical part is configuring its config.yaml to define how Prometheus metrics map to Kubernetes custom and external metrics.

# Add the Prometheus Adapter Helm repository
helm repo add k8s-at-home https://k8s-at-home.com/charts/
helm repo update

# Install Prometheus Adapter with custom rules
# We'll define the rules in a values.yaml file

Create a prometheus-adapter-values.yaml file:

# prometheus-adapter-values.yaml
prometheus:
  url: http://prometheus-kube-prometheus-stack-prometheus.monitoring.svc
  port: 9090

# Configuration for custom and external metrics rules
config: |
  rules:
  - seriesQuery: '{__name__=~"^http_requests_total$"}'
    resources:
      overrides:
        kubernetes_namespace: {resource: "namespace"}
        kubernetes_pod_name: {resource: "pod"}
    name:
      matches: "^(.*)_total$"
      as: "${1}_per_second"
    metricsQuery: sum(rate(<<.Series>>{<<.LabelMatchers>>}[5m])) by (<<.GroupBy>>)`

  - seriesQuery: '{__name__="queue_messages_total",kubernetes_namespace!="",kubernetes_pod_name!=""}'
    resources:
      overrides:
        kubernetes_namespace: {resource: "namespace"}
        kubernetes_pod_name: {resource: "pod"}
    name:
      matches: "^(.*)_total$"
      as: "${1}_depth"
    metricsQuery: sum(<<.Series>>{<<.LabelMatchers>>}) by (<<.GroupBy>>)`

  # External metrics example for a global queue depth
  - seriesQuery: '{__name__="external_queue_messages_total",queue_name!=""}'
    name:
      matches: "^external_(.*)_total$"
      as: "${1}_depth_external"
    metricsQuery: sum(<<.Series>>{<<.LabelMatchers>>}) by (queue_name)`
    external: true

Now, install the Prometheus Adapter using this values file:

helm install prometheus-adapter k8s-at-home/prometheus-adapter \
  --namespace monitoring \
  -f prometheus-adapter-values.yaml

Explanation of config.yaml rules:

• seriesQuery: A Prometheus label selector that identifies the metrics series to be processed by this rule.
• resources.overrides: Maps Prometheus labels (e.g., kubernetes_namespace, kubernetes_pod_name) to Kubernetes resource names, allowing HPA to target specific objects.
• name.matches / name.as: Defines how the Prometheus metric name is transformed into the Kubernetes custom metric name. For http_requests_total, it becomes http_requests_per_second. For queue_messages_total, it becomes queue_messages_depth.
• metricsQuery: The actual PromQL query executed by the adapter.
  • sum(rate(<<.Series>>{<<.LabelMatchers>>}[5m])) by (<<.GroupBy>>): Calculates the 5-minute average rate of http_requests_total (a counter) per pod. <<.Series>>, <<.LabelMatchers>>, and <<.GroupBy>> are templated variables replaced by the adapter based on the HPA request.
  • sum(<<.Series>>{<<.LabelMatchers>>}) by (<<.GroupBy>>): Calculates the sum of queue_messages_total (a gauge) per pod.
  • For external metrics, `external
